Multi-functional VCA blocks (Fader/Panner) AS 3365

EU customers: + VAT for customers in the EU without EU VAT registration number + shipping
Outside EU: + local taxation (VAT / trade tax / import duties) is applicable in the country of delivery + shipping
  • local_shipping Worldwide delivery with UPS/Fedex/Latvian Post
  • account_balance_wallet Pay securely with Credit Card or PayPal
  • beach_access 24 month warranty
AS3365 contains three VCA blocks, which are intended for use in musical synthesizer applications (VCA blocks, faders, panners, multiplexers, ring modulators etc.). Combining VCA1 and VCA2 provides simple stereo panning implementation. VCA3 block has additional feature – possibility of control/mixing of two input signals.

Features

  • Simplifies the design of voltage controlled audio crossfaders and panners
  • Three VCA blocks (each contains two 2-quadrant multipliers connected in series)
  • Two linear controls for each VCA
  • Simple signal mixing
  • Can combine high impedance outputs
  • High attenuation (-100 dB)
  • Low current consumption of 3 mA typ at ±12V

NB! For 100+ pcs and/or in SOIC, QFN cases, please send an inquiry to Alfa RPAR: alfa@alfarzpp.lv


Datasheet is downloadable below.
