Drum series
Sample Drum
- local_shipping Worldwide delivery with UPS/Fedex/Latvian Post
- account_balance_wallet Pay securely with Credit Card or PayPal
- beach_access 24 month warranty
Features
- Sample playback with fast trigger response (~1ms)
- Various effects for real time sample processing
- Sample recording functionality
- Manual and automatic sample slicing
- Cue point loading from WAV files
- 1V/Oct tracking
- 3 assignable CV inputs per channel
- Preset memory
- User-friendly interface
- Performance mode
- 16 GB SD card with factory preset samples included
The Sample Drum is composed of two identical parts and allows you to play back, record and slice up samples or loops directly in your modular system. For processing there are different play modes, tuning functions (including 1 V/Oct pitch tracking), virtual VCAs plus AD envelopes and realtime effects. Three freely assignable CV inputs per channel guarantee a lot of expression during performance. 16bit mono wav samples are loaded into RAM (32MB / ~ 5 minutes of sampling time) from SD card (16 GB SD card with factory preset samples comes with the module) for instantaneous playback response. All settings can be saved and recalled during live performance.
The Sample Drum comes with free factory preset sample pack developed by producers Pitch Black, Nero Bellum, T.Raumschmiere, Otto von Schirach, Raitis AG. If you use your own samples in the Sample Drum, you take all responsibility on complying with copyright laws. Please read the End User Agreement below!
FIRMWARE UPDATE CHANGELOG
The Sample Drum has received a nomination for the 35th Annual NAMM Technical Excellence & Creativity (TEC) Awards in the category of Outstanding Technical Achievement within Musical Instrument Hardware section - NAMM TEC Awards
The sample drum is very engaging as a creative tool and makes it an absolute delight for techno, acid house, glitch and far out ambient excursions. I’m getting on with the workflow quite a bit, it’s a breeze. There are tons of performance features you wouldn’t expect: Effects, CV mapping, manual performance control, envelopes. The Sample Drum already seems an indispensable piece in my system. It’s a looping, slicing animal that rocks the block. - G Storm Electronica
Audio output amplitude | 10Vptp |
Octave range | C0 – C8 |
RAM size | 32Mb, 5 minutes of samples |
Sample rate | 48kHz, 16bit |
Sample recording rate | 48kHz, 12bit |
CV input range (configurable) | 5V - +5V |
Panel width | 14HP |
Module depth | 30mm |
Power consumption | 65mA@+12V, 2mA@-12V |
Manuals book
-
User Manual — Jan. 6, 2021English
-
User Manual — July 24, 2019Japanese
Downloads cloud_download
-
Stock sample set — Aug. 4, 2021None
-
User Agreement — Dec. 28, 2020None
-
Firmware v1.9 — Dec. 2, 2019Sample Drum firmware v1.9
-
Firmware v1.8 — June 8, 2019Sample Drum firmware v1.8
